Delta News
0

Brückewell introduces SiC product series

In the recent decades, the Silicon carbide (SiC), turned out to be an excellent semiconductor material. Composed of carbon and silicon, it has been used in power applications, in which showed excellent performance, far superior to those of silicon.

Significant progress has been made in the field of the semiconductor industry, allowing the development of more and more sophisticated technologies for silicon carbide processing, which have resulted in semiconductor devices with excellent performance.

In facts, those devices have shown a remarkable capacity to reduce losses and a high switching speed in comparison to that offered by silicon. The use of silicon carbide (SiC) as a semiconductor begins to expand into multiple applications and is increasingly becoming the most suitable candidate to replace silicon in applications such as automotive and E-Bike motor control.

For these reasons, Bruckewell Semi decided to launch the production of the SiC Products, including the SiC Schottky Diode and SiC MOSFET, support the 650V to 1200V, and give the opportunity to its customers to take advantage of the benefits of SiC high-voltage power applications.



Find more on http://www.bruckewell-semi.com/index.html

cattura

0

Raystar Product Introduction – 0.91 inch OLED REX012832F

RAYSTAR REX012832F is a popular small OLED display which is made of 128×32 pixels, diagonal size 0.91 inch, it’s very suitable for wearable device. The REX012832F has the same mechanical dimension as REX012832D but having different pin assignment and supports different interface. REX012832F module is built in with SSD1306BZ controller IC; it supports I2C interface and having 14 pins FPC pintout. As to the REX012832D module is also built in with SSD1306BZ IC but it communicates via SPI interface and having 15 pins FPC pinout. The standard emitting colors for REX012832F are available in white, sky blue and yellow.

rex012832f-p-web









Read the rest of this entry »

0

Fastron News XHBHV – A leaded axial inductor designed to operate at voltage levels up to 400V

xhbhv





In addition to FASTRON’s standard leaded axial inductors the specialist adds a new ‘high voltage’ leaded axial inductor to the company’s product portfolio. Utilizing a special winding wire and a new coating, the choke can operate at voltage levels up to 400V and can withstand higher peak-voltage. Using a ferrite core the XHBHV choke offers inductance values from 100µH to 6800µH, ± 5% tolerance, maximum DCR from 0.22Ω to 14.16Ω, and current ratings (I1) from 0.22A to 1.76A.

The XHBHV inductors are a supplement to the standard leaded axial inductors for designs which are directly connected to the power line. Major applications for the XHBHV series are suppression of transients as well as EMC filtering in electrical motors and in switching power supplies used in home appliances, industrial, lighting, and automotive applications.

Read the rest of this entry »

0

BRUCKEWLL 8ETH06 8A 600V Fast Diode Benchmarking

Fast diodes are necessary components in power PFC control applications and AC to DC transfer loop. Traditionally, designs use glass passivated discrete components, that allow a Trr (the crucial parameter for such applications) of around 35ns maximum. Several years of research have led to Schottky diodes based on a planar design, allowing a Trr reduction down to under 30ns, which is ideal for high frequency applications. Bruckewell Semi has just released the 8ETH06, an 8A/ 600V Diode with an ultra-fast 18ns Trr, it uses special design techniques to optimize commutation speed while reducing die size and cost.

The chart below compares the performance of Bruckewell device with similar components available in the market.

Typical applications are: snubbers in PFC of SMPS converters, inverters, induction cooking, DC motor control, freewheeling and polarity protection components.

bruckewell
